Product Description
Harmonic ProView 7100, PVR 7K IRD with TS Decode, HD Decode, DVB-S2 and Stream DTA.
The Harmonic ProView 7100 (PVR 7K) is a 1-RU multi-format integrated receiver-decoder (IRD), transcoder, and MPEG stream processor.
It features DVB-S/S2 demodulation, transport stream (TS) descrambling via four DVB-CI slots, high-definition (HD) video decoding, and transport stream digital turnaround (DTA) processing for broadcast workflows.
Condition: Pre-owned
Key Hardware & Processing Specs
- Form Factor: 1 Rack Unit (1-RU) chassis
- Demodulation / Inputs: DVB-S/S2, DVB-ASI, and IP inputs (supporting optional quad L-band F-type 75-ohm connectors, frequency range 950–2,150 MHz)
- Descrambling: 4 transport stream descramblers with 4 integrated DVB-CI common interface slots
- Video Decoding Formats: MPEG-2 (4:2:0 8-bit), MPEG-4 AVC/H.264 (up to 4:2:2 10-bit), and HEVC (1080p60)
- Outputs: HD-SDI, SD-SDI, HDMI, analog video outputs, 4 independent ASI outputs, and up to 16 MPEG TS-over-IP outputs with 1+1 redundancy
Core Capabilities
- Transport Stream DTA & Multiplexing: Performs service-level remultiplexing, PID filtering/remapping, and PSI/SI table regeneration from any input to any output.
- Transcoding: Capable of running up to 8 channels of MPEG-4 AVC to MPEG-2 video transcoding with optional down-conversion.
- Advanced Processing: Supports T2-MI deframing to regular MPEG transport streams and deterministic remultiplexing suited for single-frequency network (SFN) distribution.
Looking for a Harmonic Broadcast Video Encoder?
Contact Midwest Digital to confirm current availability, request pricing or locate similar Harmonic broadcast encoding equipment. Contact Us
Product Videos
Custom Field
Condition Pre-owned
Harmonic ProView 7100, PVR 7K
Shipping UPS Ground
