Product Description
Harmonic Electra ELC-X2-G3 AC-HH-SS-01 B
Description:
Pre-owned and tested with licenses. This Harmonic Electra ELC-X2-G3 AC-HH-SS-01 B is a 3rd-generation Electra X2 advanced media processor. This unit is an enterprise, broadcast-grade "headend-in-a-box" server packaged in a 1-RU rack mount form factor.
It is engineered to consolidate multi-channel video encoding, high-quality graphics branding, and advanced statistical multiplexing into a single appliance. This 1-RU server is equipped with two licenses of the HWR-XOS-OPT-SDI-8IN-01.
Note: Units do not have the Electra Faceplate
Breakdown of the server:
- ELC-X2: Electra X2 series platform, which runs on the Harmonic PURE Compression Engine.
- G3: 3rd Generation hardware revision.
- AC: Dual redundant AC power supplies.
- HH: Hardware configuration (typically representing standard high-density broadcast encoders/ports).
- SS: Specific branding and integrated graphics options (e.g., on-board video graphics and SCTE automation).
- 01 B: Specific firmware, software licensing bundle, or hardware revision.
Server information:
- Product Name ProLiant DL360 Gen 10
- System ROM U32 v2.30
- Redundant System ROM U32 v2.30
- Integrated Remote Control Java
- License iLO
- Firmaware Version 2.12
License information:
Key Specifications & Features on the HWR-XOS-OPT-SDI-8IN-01
- Input Capacity: Provides 8 SD/HD-SDI inputs, 4 3G-SDI inputs, or UHD support via quadrant mode.
- Video Format Support: Supports both Standard Definition (SD) and High Definition (HD) formats.
- Hardware Type: Half-height PCI expansion card designed to integrate directly into COTS (Commercial Off-The-Shelf) servers or Harmonic's dedicated 1-RU appliance chassis.
Product Videos
Custom Field
Condition Pre-owned and Tested
Harmonic ELC-X2-G3 AC-HH Server
Shipping UPS Ground
