Product Description
Harmonic Prostream-XHR1304W PRM-X-21-AC-FF B2
Description:
The Harmonic ProStream-X (Model HR1304W) functions via a "Pay-As-You-Grow" soft-licensing tier model. The string provided breakdown outlines the physical hardware configuration alongside the software features enabled on this specific chassis.
License Key Breakdown
PRM-X-21-AC-FF: This string details the physical build configuration of the platform.- PRM-X-21: Indicates a standard 1-RU hardware generation chassis.
- AC: Signifies the appliance is configured with Dual AC Power Supply Units (PSU).
- FF: Represents full-chassis port enablement or specific front-panel I/O options (such as the standard quad 1-GbE/10-GbE SFP+ configuration).
-
Common ProStream-X Software LicensesDepending on how
304245is provisioned, the following core software capabilities can be unlocked on this platform:LIC-PRM-X-BASE: The mandatory base software license. It enables basic transport stream remultiplexing, PID remapping, and opens access to the ProStream RESTful API.LIC-PRM-X-SWITCHING: Software license for channel-by-channel automated switching. This manages Emergency Alert Systems (EAS), SCTE-18/35 triggers, and slate insertions.FW-PRM-X-2G-GATEWAY: Throughput capacity tiers. Unlocks data processing limits across the network ports up to the full hardware potential of 10-Gbps.FW-PRM-X-BISS-FIX-SRV: Security and encryption licenses. Enables DVB Common Scrambling (CSA2/CSA3), fixed-key descrambling, or BISS Mode 1 encryption.FW-PRM-XVM-DT-POOL: Statistical Multiplexing software engine. Dictates closed-loop DiviTrackIP statistical multiplexing pools across video streams.
Core Functionality
- Service Density: Capable of multiplexing and scrambling up to 2,000 simultaneous broadcast services.
- Format Support: Highly versatile, multi-codec platform that supports SD, HD, and UHD (4K) resolutions. It handles MPEG-2, MPEG-4 AVC, and HEVC video formats.
- Encryption: Integrates with major Conditional Access Systems (CAS). It is the first stream processor to offer 128-bit DVB CSA3 (as well as CSA2 and AES) encryption support, ensuring secure distribution.
Physical Dimensions
- Width: 17.11 inches (43.46 cm) — Standard 19-inch rack compliance with mounting ears.
- Height: 1.69 inches (4.29 cm) — Exactly 1-RU of vertical rack space.
- Depth: 27.83 inches (70.70 cm)
Weight
- Net Weight: 35.86 lbs (16.26 kg)
Product Videos
Custom Field
Condition Pre-owned
Harmonic ProStream-X HR1304W PRM-X-21-AC-FF B2
Shipping UPS Ground
